Single BDA solution for buildings up to 250,000 sq ft. Most cost-effective path to fire code compliance.
Get Free Site Assessment
Modern construction materials kill 80% of public safety radio signals. Without an ERCES, first responders can't communicate.
No Certificate of Occupancy without ERCES
$10,000+ daily fines for non-compliance
Personal liability for safety incidents
Insurance may deny claims
Stop-work orders on renovations
Low-E glass windows: -30dB loss
Concrete floors: -15dB per level
Metal cladding: -40dB attenuation
Parking garages: -50dB underground
Elevator shafts: Complete dead zones
Amplifies signals to -95 dBm minimum
95% coverage in general areas
99% coverage in critical areas
Guaranteed AHJ approval
Minimal maintenance required
A bi-directional amplifier (BDA) system that distributes public safety radio signals using coaxial cable throughout your building.
Donor Antenna
Roof-mounted Yagi captures outdoor signals
Directional or sector antennas for optimal donor signal acquisition
Bi-Directional Amplifier
700/800 MHz single or dual-band Bi-Directional Amplifier
Battery backup, alarm contacts, code-compliant enclosure
Coaxial Distribution Network
Low-loss coaxial cabling throughout the building
Fire-rated pathways and grounding per code
Passive RF Components
Splitters, taps, and directional couplers
Used to balance signal levels across floors and zones
Service Antennas
Ceiling or wall-mounted indoor antennas
Ceiling or wall-mounted indoor antennas
System Alarming
Code-required fault and power alarms
Dry contact outputs to FACP or monitoring panel
Architecture:
All-RF passive distribution over coaxial cable
Coverage:
Project-specific based on grid testing and building construction
Scalability:
Expansion via additional coax runs, splitters, and antennas
Redundancy:
Battery backup at BDA, redundant donor antennas (where required)
Remote Units:
Up to 32 per hub
Management:
BDA alarm monitoring via dry contacts to FACP or monitoring panel
Area coverage per code-required grid testing
Minimum signal strength (per AHJ requirement)
System availability (dependent on donor signal and power)
System availability (dependent on donor signal and power)
A BDA (Bi-Directional Amplifier) pulls public safety signal from a donor antenna mounted outside the building
That amplified RF signal is distributed entirely over coaxial cable
Passive components (splitters, taps, directional couplers) balance signal levels across the building
Each coax run feeds indoor antennas placed to meet coverage and code requirements
Our experts will assess your building and recommend the most cost-effective solution.
Your passive DAS must meet ALL requirements for AHJ approval
All Requirements Must Pass
Minimum -95 dBm signal strength in all general areas of the building
Stairwells, fire command center, pump rooms, exit corridors, elevator lobbies
All signal boosters must be listed specifically for in-building public safety
Cable routes protected by 2-hour rated enclosures or CI cable
Standby power for 24 hours quiescent + 5 minutes talk time
GFCI protected, on emergency power if available
System trouble and antenna malfunction alarms to fire panel
Recertification by qualified vendor every 12 months
Failure to meet ANY of these requirements will result in AHJ rejection. Our team ensures 100% compliance before installation begins, which is why we maintain a perfect AHJ approval rate.
From assessment to certificate of occupancy
Site Survey
RF testing Coverage mapping
Design
iBwave modeling Equipment specs
AHJ Submit
Permit filing Plan review
Installation
BDA install Antenna placement
Testing
Grid testing DAQ verification
Certification
AHJ inspection Final approval
Complete turnkey pricing.
Site Survey
All required BDA systems and components
Installation
Professional installation and setup
Acceptance
Grid testing and compliance verification
Complete Turnkey Solution
Full compliance package including 1-year warranty
What your passing AHJ report looks like
Detailed coverage maps
Compliant documentation
Support guarantee
100% AHJ approval rate across Michigan
15-Story Senior Living
Initial Coverage
51% FAIL
Final Coverage
100% PASS
Installation Time
4 Days
Total Investment
$67,500
Project Completed Successfully
50+ Regional Deployments
Scale
50+ Sites
Execution
Multi-site Delivery
Coverage Achieved
95.5%
Availability
24/7
Project Completed Successfully
Healthcare Facility
Special Challenge
MRI Shielding
Coverage Zones
6 Sectors
Compliance
JCAHO + IFC
Project Duration
3 Weeks
Project Completed Successfully
AHJ Approval Rate
Projects Completed
Emergency Support
Week Timeline
What your passing AHJ report looks like
Common questions about ERCES performance and scalability
Complete project timeline is 3-6 weeks: Site survey (1 day), Design and engineering (3-5 days), AHJ permit approval (1-2 weeks), Installation (3-5 days), Testing and commissioning (1-2 days), Final AHJ inspection (same day). Emergency fast-track available for buildings facing immediate compliance deadlines - we can complete in 10 days with expedited permitting.
No interference. Public safety DAS operates on dedicated emergency frequencies (VHF/UHF/700/800 MHz) completely separate from commercial cellular and WiFi bands. FCC Part 90 regulations require band-pass filtering to prevent any interference. Our systems include cavity filters and are tested for spurious emissions. Many buildings have both public safety and cellular DAS operating simultaneously without issues.
NFPA 1225 mandates annual testing and recertification ($2,500). Monthly visual inspections of equipment status indicators. Battery replacement every 3-5 years ($3,500). We offer comprehensive maintenance contracts including 24/7 monitoring, annual testing, emergency response, and all required documentation for $3,500-$5,000 annually. Remote monitoring can detect issues before they cause coverage problems.
This has never happened with our installations - we maintain a 100% AHJ approval rate. Our design process includes pre-approval coordination with your local AHJ. We test all systems before the official inspection to ensure compliance. If any issues were to arise, we would resolve them at no additional cost. Our designs are conservative to ensure we exceed minimum requirements by a comfortable margin.
Yes, our systems integrate with all major fire alarm control panels (FACP) including Simplex, Notifier, Edwards, Fire-Lite, and Honeywell. We provide supervised dry contact outputs for system trouble and antenna fault monitoring. Integration typically requires 2-4 additional zones on your FACP. We coordinate with your fire alarm contractor to ensure seamless integration without affecting existing certifications.
Our systems support all public safety bands: VHF (150-174 MHz), UHF (450-470 MHz), 700 MHz Public Safety (763-775/793-805 MHz), and 800 MHz (806-824/851-869 MHz). We determine the exact frequencies used by your local fire department during the site survey. Multi-band systems are available for jurisdictions using multiple radio bands. All equipment is FCC Part 90 certified for public safety use.
Our ERCES experts are standing by to help with your specific situation.
Fiber-optic backbone with distributed BDAs for buildingsup to 1M sq ft. Perfect for campuses and complexlayouts.
Get Free Site Assessment
Modern construction materials kill 80% of public safety radio signals. Without an ERCES, first responders can't communicate.
No Certificate of Occupancy without ERCES
$10,000+ daily fines for non-compliance
Personal liability for safety incidents
Insurance may deny claims
Stop-work orders on renovations
Low-E glass windows: -30dB loss
Concrete floors: -15dB per level
Metal cladding: -40dB attenuation
Parking garages: -50dB underground
Elevator shafts: Complete dead zones
Amplifies signals to -95 dBm minimum
95% coverage in general areas
99% coverage in critical areas
Guaranteed AHJ approval
Minimal maintenance required
Combines fiber-optic signal transport with localized coaxial distribution, using a centralized BDA and strategically placed remote nodes to deliver reliable public safety coverage throughout complex buildings.
Donor Antenna
Multiple roof antennas for carrier diversity
Sector antennas, spatial diversity
Master BDA Unit
700/800 single or dual band fiber DAS master unit
Redundant power, hot-swappable modules
Fiber Optic Expansion Unit
Single mode fiber to remote units
OS2 fiber, LC connectors, OTDR tested
Remote Units
Distributed amplifiers throughout building
Fiber-fed, local coax distribution
Service Antennas
Targeted coverage areas per floor/zone
Directional/omni patterns per zone
Network Management
Centralized monitoring and control
SNMP v3, web interface, alerts
Architecture:
Fiber backbone + coax distribution
Coverage:
Up to 250,000 Sq Ft
Scalability:
Modular expansion capability
Redundancy:
Dual fiber paths, backup power
Remote Units:
Up to 32 per hub
Management:
SNMP, web-based monitoring
Area coverage
Min Signal
Reliability
Monitoring
A BDA (Bi-Directional Amplifier) pulls signal from a donor antenna outside the building.
That signal is converted and sent over fiber to remote units throughout the building
Each remote unit feeds coaxial cable to multiple antennas in nearby areas
Radios talk up and down through the system
Our experts will assess your building and recommend the most cost-effective solution.
Your passive DAS must meet ALL requirements for AHJ approval
All Requirements Must Pass
Minimum -95 dBm signal strength in all general areas of the building
Stairwells, fire command center, pump rooms, exit corridors, elevator lobbies
Remote units strategically placed to eliminate signal loss
BDAs, fiber distribution units, and remote units
Listed specifically for in-building public safety systems
Fiber and coax pathways protected by 2-hour rated enclosures or CI cable
Head-end and remote units supported by 24-hour standby + 5 minutes talk time
GFCI protected, Emergency power where available
System trouble, power loss, and antenna faults
Monitored through FACP or approved monitoring interface
System recertification every 12 months Including fiber integrity and end-to-end RF performance
Failure to meet ANY of these requirements will result in AHJ rejection. Our team ensures 100% compliance before installation begins, which is why we maintain a perfect AHJ approval rate.
From assessment to certificate of occupancy
Site Survey
RF testing Coverage mapping
Design
iBwave modeling Equipment specs
AHJ Submit
Permit filing Plan review
Installation
BDA install Antenna placement
Testing
Grid testing DAQ verification
Certification
AHJ inspection Final approval
Complete turnkey pricing.
Site Survey
All required BDA systems and components
Installation
Professional installation and setup
Acceptance
Grid testing and compliance verification
Complete Turnkey Solution
Full compliance package including 1-year warranty
What your passing AHJ report looks like
Detailed coverage maps
Compliant documentation
Support guarantee
What your passing AHJ report looks like
15-Story Senior Living
Initial Coverage
51% FAIL
Final Coverage
100% PASS
Installation Time
4 Days
Total Investment
$67,500
Project Completed Successfully
50+ Regional Deployments
Scale
50+ Sites
Execution
Multi-site Delivery
Coverage Achieved
95.5%
Availability
24/7
Project Completed Successfully
Healthcare Facility
Special Challenge
MRI Shielding
Coverage Zones
6 Sectors
Compliance
JCAHO + IFC
Project Duration
3 Weeks
Project Completed Successfully
AHJ Approval Rate
Projects Completed
Emergency Support
Week Timeline
Common questions about ERCES performance and scalability
Complete project timeline is 3-6 weeks: Site survey (1 day), Design and engineering (3-5 days), AHJ permit approval (1-2 weeks), Installation (3-5 days), Testing and commissioning (1-2 days), Final AHJ inspection (same day). Emergency fast-track available for buildings facing immediate compliance deadlines - we can complete in 10 days with expedited permitting.
No interference. Public safety DAS operates on dedicated emergency frequencies (VHF/UHF/700/800 MHz) completely separate from commercial cellular and WiFi bands. FCC Part 90 regulations require band-pass filtering to prevent any interference. Our systems include cavity filters and are tested for spurious emissions. Many buildings have both public safety and cellular DAS operating simultaneously without issues.
NFPA 1225 mandates annual testing and recertification ($2,500). Monthly visual inspections of equipment status indicators. Battery replacement every 3-5 years ($3,500). We offer comprehensive maintenance contracts including 24/7 monitoring, annual testing, emergency response, and all required documentation for $3,500-$5,000 annually. Remote monitoring can detect issues before they cause coverage problems.
This has never happened with our installations - we maintain a 100% AHJ approval rate. Our design process includes pre-approval coordination with your local AHJ. We test all systems before the official inspection to ensure compliance. If any issues were to arise, we would resolve them at no additional cost. Our designs are conservative to ensure we exceed minimum requirements by a comfortable margin.
Yes, our systems integrate with all major fire alarm control panels (FACP) including Simplex, Notifier, Edwards, Fire-Lite, and Honeywell. We provide supervised dry contact outputs for system trouble and antenna fault monitoring. Integration typically requires 2-4 additional zones on your FACP. We coordinate with your fire alarm contractor to ensure seamless integration without affecting existing certifications.
Our systems support all public safety bands: VHF (150-174 MHz), UHF (450-470 MHz), 700 MHz Public Safety (763-775/793-805 MHz), and 800 MHz (806-824/851-869 MHz). We determine the exact frequencies used by your local fire department during the site survey. Multi-band systems are available for jurisdictions using multiple radio bands. All equipment is FCC Part 90 certified for public safety use.
Our ERCES experts are standing by to help with your specific situation.
Response within 4 hours • No obligation • NDA available
